Key specifications
- Product Type
- In Situ Raman Electrochemical Cell
- Application
- In Situ / Operando Raman Spectroscopy
- Cell Configuration
- Two-Compartment Electrochemical Cell
- Anode Chamber
- Provided
- Cathode Chamber
- Provided
- Membrane
- Membrane placement provided
Full details in the Specifications tab below.
In Situ Raman Electrochemical Cell for Operando Raman Spectroscopy
Also known as: operando Raman cell, spectroelectrochemical Raman cell
Made to order
GST invoice · Secure checkout · Datasheet on request
Product summary
In Situ Raman Electrochemical Cell The In Situ Raman Electrochemical Cell is a specialized electrochemical cell designed for in situ and operando Raman spectroscopy of electrochemical reactions.
In Situ Raman Electrochemical Cell The In Situ Raman Electrochemical Cell is a specialized electrochemical cell designed for in situ and operando Raman spectroscopy of electrochemical reactions.
An in situ Raman electrochemical cell has an optical window, so a Raman spectrometer can observe an electrode while it reacts. It shows what is on the catalyst surface during the reaction, which ordinary measurements cannot.
Typical uses
- Operando study of catalyst surfaces
- CO₂ reduction and water splitting mechanisms
- Identifying reaction intermediates
Care and handling
- Keep the window clean and free of scratches.
- Check seals before each run, and align the laser with care.
Engineered for laboratory and industrial use. Contact us for custom specifications, bulk quantities, or application guidance.
What you get
- 1 × In Situ Raman Electrochemical Cell for Operando Raman Spectroscopy
- Test/QC certificate on request
- GST invoice
- Brand
- METNMAT
- Minimum order
- 1 pc
- Product Type
- In Situ Raman Electrochemical Cell
- Application
- In Situ / Operando Raman Spectroscopy
- Cell Configuration
- Two-Compartment Electrochemical Cell
- Anode Chamber
- Provided
- Cathode Chamber
- Provided
- Membrane
- Membrane placement provided
- Optical Window
- Quartz
- Quartz Window Diameter
- Ø35 mm
- Electrolyte Connections
- Anolyte / Catholyte Inlet
- Gas Connection
- Gas Inlet
- Reference Electrode
- Dedicated RE Port
- Counter Electrode
- Dedicated CE Port
- Overall Dimensions
- 105 × 75 mm
- Customization
- Available
- Applications
- In Situ Raman Spectroscopy, Operando Raman Electrochemistry, Electrochemical Reaction Monitoring, Electrocatalysis Research, CO₂ Reduction Reaction (CO₂RR), Water Electrolysis, HER & OER Studies, Catalyst Characterization, Electrode/Electrolyte Interface Studies, Energy Conversion Research
- Key Features
- Designed for in situ / operando Raman spectroscopy; Quartz optical window for Raman laser access; Separate anode and cathode chambers; Membrane-based two-compartment configuration; Integrated electrolyte flow channels; Gas inlet for controlled gas delivery; Dedicated reference electrode port; Dedicated counter electrode port; Suitable for real-time electrochemical characterization; Compact laboratory-scale design; Custom configurations available
Datasheets, brochures & certificates for this product are available on request — use “Request a quote” and we'll share them.
- Free shipping within India. We also ship worldwide; international freight is confirmed after you order.
- GST invoice provided on every order.
- Dispatch lead times vary by item; bulk orders may take longer.
- No refunds. Damaged, defective, or incorrect items are eligible for a free replacement within 7 days of delivery — see our Replacement Policy.
About this in situ Raman electrochemical cell
- Optical window: Quartz.
- The price is ₹1,49,999 plus 18% GST, which comes to ₹1,76,999, with free shipping in India.
Compare other in situ Raman electrochemical cell models
| Model | Price incl. GST |
|---|---|
| Dual Chambered In-Situ Raman Spectroscopy Cell With Single Light Window | ₹1,76,999 |
More on CO₂ electrolysis cells
Our guide, how to choose a co₂ reduction cell, and common questions are on the CO₂ Electrolyzers and Gas Diffusion Flow Cells page.
Frequently asked questions
- What is the price of this in situ Raman electrochemical cell in India?
- The In Situ Raman Electrochemical Cell for Operando Raman Spectroscopy costs ₹1,76,999 including GST, with free shipping within India and a GST invoice.
- Is In Situ Raman Electrochemical Cell for Operando Raman Spectroscopy in stock?
- Yes — In Situ Raman Electrochemical Cell for Operando Raman Spectroscopy is in stock.
- Where is it made?
- Country of origin: India.
